Post Office Tower - London
| |||||||
|
1 / 27
50v DC busbars - the left block are covered in a blue plastic insulation
2 / 27
Busbars - 50v DC but very high current
3 / 27
Equipment Cabinets - Museum TE/TRS, 11 K.V. Switchboard
4 / 27
Power Cabinets - Museum TE/TRS, medium voltage switchboard with combined transformer cubicles
5 / 27
Equipment - Museum TE/TRS, Engine Room, view of link voltage regulators
6 / 27
Equipment - 50v high current switch which is manually operated by a geared system
7 / 27
Equipment - 50v high current switch which is manually operated by a geared system
8 / 27
Equipment Cabinet
9 / 27
Equipment Cabinet for Mircowave transmission
10 / 27
Control desk at the Televison Switching Centre
11 / 27
Control desk at the Televison Switching Centre
12 / 27
Equipment Cabinet - two paper recodres can be in Rack 2
13 / 27
Cable termination racks
14 / 27
Equipements racks - Mobile testers on show
15 / 27
Equipment Racks - SHF, GEC 6000Mc/s B15
16 / 27
Equipment Racks - SHF, GEC 6000Mc/s B15
17 / 27
Microwave Transmitter Cabinets for Tembrary 7000Mc/s Equipment awaiting installation
18 / 27
Switching Console
19 / 27
Building work in progress - two workers on a gantry
20 / 27
Patch Rack - Engineer installing pach cables
21 / 27
Televison Switching Centre
22 / 27
Control Desk in the Television Switching Centre
23 / 27
Control Desk in the Television Switching Centre
24 / 27
Control Desk in the Television Switching Centre
25 / 27
Control Desk in the Television Switching Centre
26 / 27
Control Desk in the Television Switching Centre
27 / 27
Television Signal Monitoring Station
|
|||||||
